C-axis parameters
|
| Table diameter | 500mm |
| Horizontal bearing capacity | 400kg
|
| Vertical bearing capacity | 300kg
|
| C-axis rated torque | 350Nm
|
| Maximum torque of C-axis | 665Nm |
| Maximum speed of C-axis | 100rpm |
| C-axis tightening torque | 2000Nm (60bar) |
| C-axis angle range | nx360° |
| C-axis encoder type | absolute |
| C-axis positioning accuracy | 8"VDI3441 |
| C-axis repeated positioning accuracy | 4"VDI3441 |
| Sealing method | Contact sealing |
A-axis parameters
|
A-axis rated torque
| 700Nm |
| Maximum torque of A-axis | 1330Nm |
| A-axis maximum speed | 100rpm
|
| A-axis tightening torque | 4000Nm (60bar) |
| A-axis angle range | ±120° |
| A-axis encoder type | absolute
|
| A-axis positioning accuracy | 8"VDI3441 |
| A-axis repeated positioning accuracy | 4"VDI3441 |
| Total weight | 625kg |
