C-axis parameters
|
| C1 countertop diameter | 500x700mm
|
| C1 countertop weight | 300kg
|
| C1 axis rated torque | 350Nm
|
| C1 axis maximum torque | 530Nm
|
C1 axis maximum speed
| 30rpm |
| C1 axis rated power | 3.7kw |
| C1 axis rated current | 19A
|
| C1 axis rated voltage | 380V |
| C1 axis tightening torque | 2000（60bar）Nm |
| C1 axis angle range | nx360° |
| C1 axis encoder type | absolute |
C1 axis positioning accuracy
| 8″VDI3441
|
C1 axis repeated positioning accuracy
| 4″VDI3441
|
C2 countertop diameter
| 500x700mm
|
C2 Table Weight
| 300kg
|
C2 axis rated torque
| 350Nm
|
C2 axis maximum torque
| 530Nm
|
C2 axis maximum speed
| 30rpm
|
C2 axis rated power
| 3.7kw
|
C2 axis rated current
| 19A
|
C2 axis rated voltage
| 380V
|
C2 axis tightening torque
| 2000（60bar）Nm
|
C2 axis angle range
| nx360°
|
C2 axis encoder type
| Absolute formula
|
C2 axis positioning accuracy
| 8″VDI3441
|
C2 axis repeated positioning accuracy
| 4″VDI3441
|
B Table diameter
| 650mm
|
B-axis rated torque
| 830Nm
|
Maximum torque of B-axis
| 1384Nm
|
Maximum speed of B-axis
| 30rpm
|
B-axis rated power
| 3.66kw
|
B-axis rated current
| 14.8A
|
B-axis rated voltage
| 380V
|
B-axis tightening torque
| 4000（60bar）Nm
|
B-axis angle range
| ±180°
|
B-axis encoder type
| Absolute formula
|
B-axis positioning accuracy
| 8″VDI3441
|
B-axis repeated positioning accuracy
| 4″VDI3441
|
Total weight
| 1350Kg
|
